13 Kv Heat Shrinkable Joints

Name: 13 Kv Heat Shrinkable Joints
Brand: GLOBAL POWER INDUSTRIES
Price: 3500 INR
Availability: InStock

Price 3500 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

13 Kv Heat Shrinkable Joints Specification

Operating Temperature
-40C to +90C Celsius (oC)

Insulation
PTFE heat shrink

Number of Conductor
1 / 3 core options available

Diameter
For cables 12 mm to 45 mm OD (range variants) Millimeter (mm)

Cable Type
XLPE/PVC insulated power cables

Install Type
Heat shrinkable (requires heat gun/torch)

Conductor Shape
Stranded/Round

Dielectiric Strength
>14 kV/mm Newtons per Millimetre Squared (N/mm2)

Core Number
1, 2, 3, or specified upon order

Features
Reliable sealing, UV resistance, moisture proof, electrical insulation, corrosion resistant

Conductor Type
Single core/Multicore compatible

Weight
Varies by size; approx. 0.7 kg to 2.5 kg Kilograms (kg)

Rated Temperature
-40C to +90C Celsius (oC)

Tensile Strength
>12 MPa Megapascals (MPa )

Armored Material
Steel tape/None (depending on type)

Usage & Applications
Power transmission & distribution | Substations | Industrial installations

Locking Type
Mechanical fit/shrink fit sealing

Core Material
Copper

Product Type
Heat Shrinkable Joint

Length
Standard and customized lengths available Millimeter (mm)

Voltage
13 kV

Insulation Material
PTFE

Conductor Material
Copper

Jacket Material
Cross-linked polyolefin

Storage Temperature
0C to 40C Celsius (oC)

Connector Color
Black / As per requirement

Shield Material
Copper mesh

Jacket Color
Any Color

Dimension (L*W*H)
Varies per cable size; typical standard dimensions available Meter (m)

Color
Standard or as specified

Material
Cross-linked Polyolefin & PTFE

Size
Cable size specific (as per cable diameter range)

Flame Retardant
Yes

UV Resistance
Yes

Halogen Free
Yes

Resistant to Chemicals & Abrasion
Yes

Service Life
25 years (typical)

Kit Contents
Heat shrink tubes, insulating tapes, copper mesh, connectors

Installation Time
15 to 30 minutes

Waterproof Rating
IP68

Test Voltage
25 kV for 5 minutes

Shrink Ratio
3:1

Standards Compliance
IEC 60502, IS 13573, IEEE 404

Packing Type
Individual kit with gloves, instructions

Compatibility
XLPE, PVC, PILC cable types up to 13kV

Environmental Resistance
Excellent (moisture, dust, chemicals)

13 Kv Heat Shrinkable Joints Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash Advance (CA)

Supply Ability
5000 Pieces Per Month

Delivery Time
2-3 Days

Main Domestic Market
All India

About 13 Kv Heat Shrinkable Joints

Discover our unmatchable 13 kV Heat Shrinkable Joints, engineered for top performance and reliable electrical insulation. With a reduced price and competitive pricing, these renowned joints are perfect for XLPE, PVC, and PILC cable types up to 13kV. Featuring an impressive IP68 waterproof rating, 3: 1 shrink ratio, and compliance with IEC 60502, IS 13573, and IEEE 404 standards, they assure reliable sealing and unyielding environmental resistance. Manufactured with halogen-free, flame retardant PTFE and cross-linked polyolefin, the kit includes everything required for rapid, flawless installation in just 1530 minutes. Expect up to 25 years service life.

Competitive Advantages & Applications of 13 kV Heat Shrinkable Joints

Our 13 kV Heat Shrinkable Joints offer competitive advantages such as rapid installation, unmatchable environmental resistance, and compliance with international standards. Used extensively in power transmission, distribution, substations, and industrial installations, these joints provide perfect sealing against moisture and dust. Constructed from renowned cross-linked polyolefin and PTFE, they are UV resistant, flame retardant, and halogen free, ensuring reliable performance and longevity in the harshest environments.

Payment Terms and Export Markets for 13 kV Heat Shrinkable Joints

Flexible payment options are available to suit your proposal amount for our 13 kV joints. Our main domestic market covers all of India, catering to both private and public sector requirements. We extend our offer to main export markets in Asia, Africa, the Middle East, and Europe. With reliable delivery channels, our heat shrinkable joints are delivered on time, making us a trusted exporter and importer globally.

FAQs of 13 Kv Heat Shrinkable Joints:

Q: How do I install the 13 kV Heat Shrinkable Joint?

A: Installation is straightforward and typically takes 15 to 30 minutes using a heat gun or torch. Detailed instructions and gloves are included in each kit to ensure a secure and reliable connection.

Q: What are the main benefits of choosing your 13 kV Heat Shrinkable Joints?

A: Our joints provide perfect sealing, unmatchable resistance to chemicals, UV, and moisture, and are flame retardant and halogen free. This ensures safety, durability, and longevity in power transmission and distribution applications.

Q: Where can these joints be effectively used?

A: They are ideal for subterranean power transmission, substations, industrial installations, and any application requiring secure cable joining up to 13 kV. Theyre compatible with XLPE, PVC, and PILC cable types.

Q: What materials make up the 13 kV Heat Shrinkable Joint kit?

A: Each kit includes cross-linked polyolefin and PTFE heat shrink tubes, copper mesh, connectors, insulating tapes, and comes with gloves and installation instructions.

Q: When should I consider using these joints instead of alternatives?

A: Choose these joints when you need reliable, long-lasting performance in challenging environments where electrical insulation, chemical resistance, and easy installation are paramount.

Q: How is product quality ensured?

A: Our products comply with international standards IEC 60502, IS 13573, and IEEE 404, and are tested at 25 kV for 5 minutes to guarantee performance and safety.
