High Voltage Cable Jointing Kit

Name: High Voltage Cable Jointing Kit
Brand: GLOBAL POWER INDUSTRIES
Price: 1500 INR
Availability: InStock

Price 1500 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

High Voltage Cable Jointing Kit Specification

Core Material
Copper

Dielectiric Strength
24 kV/mm Kilopascals (KPa)

Weight
Varies with kit size (approx. 2 to 6 kg) Kilograms (kg)

Tensile Strength
13.8 MPa Megapascals (MPa )

Usage & Applications
Outdoor / Indoor Cable Jointing, Underground and Overhead Installations

Core Number
1, 3, or 4

Conductor Type
Stranded

Diameter
25 mm to 120 mm (depends on cable) Millimeter (mm)

Impedance
As per IEC/IS Standard Milliampere (mA)

Rated Temperature
Up to 90C continuous Celsius (oC)

Locking Type
Mechanical/Compression Fittings

Cable Type
High Voltage Power Cables

Operating Temperature
-20C to +90C Celsius (oC)

Insulation
PTFE / XLPE

Install Type
Heat Shrink or Cold Shrink Method

Conductor Shape
Round

Number of Conductor
1, 3, 4 Core Options

Features
High mechanical strength, moisture-proof, heat and chemical resistance, easy installation

Armored Material
Galvanized Steel Wire/Strip (for armoured cable kits)

Product Type
High Voltage Cable Jointing Kit

Length
Customized as per requirement Millimeter (mm)

Voltage
11 kV to 33 kV (High Voltage Range)

Insulation Material
PTFE

Application
Other

Conductor Material
Copper

Jacket Material
Cross-linked Polyethylene (XLPE) / PVC

Storage Temperature
-20C to +50C Celsius (oC)

Connector Color
Black / Red / Customized

Shield Material
Copper Tape or Wire

Jacket Color
Any Color

Dimension (L*W*H)
As per cable size and specification Millimeter (mm)

Material
Polymeric / Resin Compounds and Heat Shrink Tubing

Color
Black, Red, Yellow, Blue (Custom on request)

Size
As per cable diameter (customizable)

RoHS Compliant
Yes

Accessories Included
Connectors, Tubes, Abrasive Paper, Instruction Manual

Water Tightness
IP68 Rated

Voltage Withstand Test
36 kV (for 11 kV kit), 78 kV (for 33 kV kit)

Halogen Free
On request

UV Resistant
Yes

Shrink Ratio
3:1 (Heat Shrink Type)

Minimum Bending Radius
10 x Cable Diameter

Packing
Individual Set in Carton Box

Standards Complied
IEC 60502-4, IS: 13573

Installation Tools Required
Standard Hand Tools

Flame Retardant
Yes

High Voltage Cable Jointing Kit Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash Advance (CA)

Supply Ability
5000 Pieces Per Month

Delivery Time
2-3 Days

Main Domestic Market
All India

About High Voltage Cable Jointing Kit

Grab the Valiant High Voltage Cable Jointing Kit and unlock flawless connectivity with instant savings. Remarked for its high mechanical strength, moisture-proof and heat resistance, this kit is crafted to IEC 60502-4 and IS 13573 standards. Its flawless build includes flame retardant, UV resistant, IP68 water tightness, and optional halogen-free materials. With a 3: 1 shrink ratio, it ensures robust jointing for power transmission, distribution, and industrial installations. Approvals by accredited labs, RoHS compliance, and custom length options round off this high-performance kit, ready for reliable, long-lasting connections.

Application Versatility and Industrial Use

The High Voltage Cable Jointing Kit is engineered for power transmission, distribution networks, and industrial installation sites. Suitable for both outdoor and indoor usage, it excels in underground and overhead cable jointing across plants, substations, and industrial environments. Users can opt for heat shrink or cold shrink installation, making it adaptable for new construction and maintenance operations. Applications extend to any scenario requiring durable, moisture-proof and valiant cable connectivity.

Swift Delivery and Verified Excellence

Outlay for every kit is efficient, promising timely packing & dispatch from India to your main domestic market. Each jointing kit undergoes rigorous type testing verified by accredited labs, holding certifications like RoHS and IEC compliance. With individual carton box packing for safe exchange and transport, expect quick turnaround and quality assurance. Delivery time may vary based on order size and customization, consistently ensuring reliability throughout the supply chain.

FAQs of High Voltage Cable Jointing Kit:

Q: How is the High Voltage Cable Jointing Kit installed?

A: It is installed using heat shrink or cold shrink methods, requiring standard hand tools, and comes with connectors, tubes, abrasive paper, and an instruction manual.

Q: What industries and environments can use this kit?

A: This kit is suitable for power transmission, distribution networks, industrial installations, and both outdoor and indoor cable jointing, including underground and overhead applications.

Q: When does the kit comply with halogen-free requirements?

A: Halogen-free material options are available on request to meet specific safety standards or regulatory requirements in hazardous environments.

Q: Where is this product mainly distributed?

A: The kit is dispatched from India and serves a variety of domestic and international markets, including industrial plants, construction sites, and utilities.

Q: What certifications does the jointing kit hold?

A: It is type tested by accredited laboratories and is compliant with IEC, IS standards as well as RoHS certification, affirming its quality and safety.

Q: What are the benefits of using this cable jointing kit?

A: Users gain a durable, moisture-proof, heat and chemical resistant solution with high mechanical strength, supported by a flawless track record and quick installation process.
